Manual Butterfly Valves Manufacturers

VATTTEN manual butterfly valves come in three different structures: centerline, double eccentric, and triple eccentric butterfly valves.

For the water treatment industry, we typically choose the centerline structure, which helps reduce costs effectively.

For the gas purification industry, we recommend using the double eccentric butterfly valve. Its design ensures a service life of up to 700,000 cycles, preventing valve leakage.

The triple eccentric butterfly valve is capable of withstanding pressures up to 64 kg, making it ideal for applications involving high temperatures, high pressures, and solid materials.

Additionally, VATTTEN offers sanitary clamp butterfly valves, which are highly popular in the food-grade powder industry and have a strong market presence.
